DP 1010 Spray

Features

LEED Qualified
GREENGUARD Gold Certified
UL Listed
Low VOC
Meets Requirements of NFPA 90A & 90B, ASTM E-84, and UL-723
Excellent Water and U.V. Resistance
Meets CDPH Emission Requirements
Excellent Workability
Meets FDA, USDA, and EPA Standards
Crack and Peel Resistant
Mold and Mildew Resistant
Excellent Dry Adhesion
Indoor and Outdoor Usage
Minimal Shrinkage
Sag Resistant
Paintable with latex or epoxy paints after cured

Properties

Color

Gray

Base

Water

Chemical Family

Synthetic Latex

Solids Content

70 ± 2%

Viscosity

Approx. 100,000 - 200,000 cps

Application Temperature

40°F - 110°F

Storage

40°F - 110°F. Do not freeze. If product freezes, allow to return to room temperature before applying.

Freeze/Thaw Stability

5 cycles no deterioration (DPTM-20)

Service Temperature

-25°F - 200°F

Flammability

Non-flammable wet or dry

Flash Point

No flash to boiling

Shelf Life

2 Years (unopened containers)

Cure Time

24-72 hours depending on temperature, humidity, and application

Coverage

Dependent on application thickness, 40-80 sq. ft. at 20-40 wet mils

Clean Up

Use warm water and soap

Packaging

50 gallon drums, 53 gallon drums

Pressure Classes

Meets all SMACNA pressure classes

Seal Classes

Meets all SMACNA seal classes

VOC

≤ 3 g/l

Downloads

Type

Document Name

File Size

Safety Data Sheet

Document Name DP-1010-SPRAY-SDS

File Size 231.2 KB

View

Technical Data Sheet

Document Name DP 1010 SPRAY WATER BASED DUCT SEALANT

File Size 838.1 KB

View

Certifications

Additional information

Brand:

Design Polymerics

Technology:

Acrylic

Application:

Building Envelope and Components HVAC

Market:

Building Construction

Available Packaging

Size

Part Number

Quantity


Size 54 GALLON DRUMS

Part Number TEMP

Quantity 1
