DP 1050 Residential Duct Sealant | Fiber Reinforced Sealant

Features

LEED V4 Qualified
GREENGUARD Gold Certified
UL Listed
Low VOC
Meets Requirements of NFPA 90A & 90B, ASTM E-84, and UL-723
Meets CDPH Emission Requirements
Excellent Water and U.V. Resistance
Meets FDA, USDA, and EPA Standards
Excellent Workability
Crack and Peel Resistant
Mold and Mildew Resistant
Excellent Dry Adhesion
Indoor and Outdoor Usage
Sag Resistant
Paintable with latex or epoxy paints after cured

Properties

Color

Gray or White

Base

Water

Chemical Family

Synthetic Latex

Solids Content

66 ± 2%

Viscosity

Approx. 300,000 - 400,000 cps

Shore A Hardness

Greater than 20

Application Temperature

40°F - 110°F

Storage Temperature

40°F - 110°F. Do not freeze. If product freezes, allow to return to room temperature before applying

Freeze/Thaw Stability

5 cycles no deterioration (DPTM-20)

Service Temperature

-25°F - 200°F

Flammability

Non-flammable wet or dry

Flash Point

No flash to boiling

Shelf Life

2 Years (unopened containers)

Cure Time

24-72 hours depending on temperature, humidity, and application

Coverage

Dependent on application thickness, 40-80 sq. ft. at 20-40 wet mils

Clean Up

Use warm water and soap

Packaging

1/12 gallon tubes, 1 gallon pails, 5 gallon pails, 54 gallon drums

Pressure Classes

Meets all SMACNA pressure classes

Seal Classes

Meets all SMACNA seal classes

VOC

≤ 3 g/l

Downloads

Certifications

Additional information

Brand:

Design Polymerics

Technology:

Acrylic

Application:

Building Envelope and Components HVAC

Market:

Building Construction

Available Packaging

Size

Part Number

Quantity


Size 1/12 GALLON TUBES (10.2 oz)

Part Number TEMP

Quantity 1

Size 1 GALLON PAILS

Part Number TEMP

Quantity 1


Size 2 GALLON

Part Number TEMP

Quantity 1

Size 5 GALLON PAILS

Part Number TEMP

Quantity 1

Size 54 GALLON DRUMS

Part Number TEMP

Quantity 1
