EPO-TEK® 353NDP

Properties

Feature

Advantage

Benefit

HI-REL version of 353ND 

Advantage Withstand harsher and more demanding operating conditions

Benefit Provide reliable bond, especially in demanding markets such as Datacom and Telecom, Aerospace, Defense, and Automotive 

Low outgassing epoxy (0.09% at 200⁰C)

Advantage Eliminate condensation and fog on the photonics window from outgassed byproducts 

Benefit Help in optical or electro-optical components and sensitive electrical processes

> 15kg die shear strength after 2000 hours of 85⁰C/85% relative humidity 

Advantage Offer reliable structural bonding for applications

Benefit Support the leap from 400G to 800G and 1.6T high-speed optical transceiver in the AI and ML era

Excellent chemical resistance

Advantage Enable the end product to operate in harsh environments with chemical exposure

Benefit Help in applications with exposure to harsh chemicals, especially in automotive and aviation markets

Curing at 120dC @ 1hour

Advantage Lower curing temperature

Benefit Suitable for high-temperature sensitive applications without compromising the bonding strength

Spectra Transmission ≥ 98%@800-1000n ≥ 95% @1100-1600nm

Advantage Transmitting light in the optical pathway from 800- 1550 nm range

Benefit Suitable for optical light path applications with low signal loss

Downloads

Type

Document Name

File Size

Safety Data Sheet

Document Name EPO-TEK® 353NDP SDS

File Size 986.7 KB

View

Technical Data Sheet

Document Name EPO-TEK® 353NDP TDS

File Size 1.0 MB

View

Brand:

Epoxy Technology

Application:

Datacom and Telecom E-mobility Microelectronics/Semiconductors Off-shore Drilling Optical Sensors and Camera Modules

Market:

Aerospace and Defense Automotive and Transportation Optical, Datacom and Telecom
